EMPTY CONTROL STATION XAPM METAL 6 OPENI

EMPTY CONTROL STATION XAPM METAL 6 OPENI

XAPM3206https://download.schneider-electric.com/files?p_Doc_Ref=XAM-P_662_CPSCT17001&p_File_Type=rendition_4000_pngdie-cast empty control station - XAPM - Ø22- zinc alloy- 6 openings in 2 columns. Label: Harmony XAM, XAP - range of product: Harmony XAP - number of cut-out: 6 cut-outs - colour of base of enclosure: blue - colour of cover: blue - material: zinc alloy - cable entry: 1 hole with blanking plug for cable gland, clamping capacity: 18-18 mm, 1 hole without blanking plug for cable gland, clamping capacity: 18-18 mm - device mounting: flush - product or component type: die-cast empty control station - IP degree of protection: IP65 conforming to IEC 60529, IP69 conforming to NF C 20-010, IP69K - device short name: XAPM - product destination: for Ø 22 mm control and signalling units - product front plate size: 80 x 175 mm - usable depth: 49 mm - Range Presentation: Functions: on, off, on-off, emergency stop.
XAP M molded, drilled and undrilled enclosures
- Zinc alloy, blue enclosure and lid- Drilling: 1 to 8 holesXAM W elbowed and drilled enclosures - Aluminium alloy, gray enclosure clearly and gray lid anthracite or yellow,- Drilling : 1 to 7 holes.
XAP E drilled, flush-mounting enclosures
- Faceplate in unpainted brushed aluminium- Drilling: 1 to 5 holes
- Compliance with IEC, UL, CSA standards- IP 65 dust and damp proofing- Same characteristics as components in the Harmony range - Range Benefits: At the heart of the action This range of industrial IP 67 enclosures combines simple installation, configuration flexibility, and robust construction. When combined with the metal buttons and LEDs of the Harmony range, it is perfectly suited for many typical operator dialog functions. - Range Application Presentation:
- Industry: machine manufacturers (automotive, textiles, timber)- Service sector and infrastructure: energy distribution, public works, building, airports
GBP
Stock Code: XAPM3206
Call for availability on 0345 030 60 80
This item is Obsolete
119999.99£99,999.99 (exc VAT) per 1
£119,999.99 (inc VAT)
Quantity: - +

Product Description

die-cast empty control station - XAPM - Ø22- zinc alloy- 6 openings in 2 columns. Label: Harmony XAM, XAP - range of product: Harmony XAP - number of cut-out: 6 cut-outs - colour of base of enclosure: blue - colour of cover: blue - material: zinc alloy - cable entry: 1 hole with blanking plug for cable gland, clamping capacity: 18-18 mm, 1 hole without blanking plug for cable gland, clamping capacity: 18-18 mm - device mounting: flush - product or component type: die-cast empty control station - IP degree of protection: IP65 conforming to IEC 60529, IP69 conforming to NF C 20-010, IP69K - device short name: XAPM - product destination: for Ø 22 mm control and signalling units - product front plate size: 80 x 175 mm - usable depth: 49 mm - Range Presentation: Functions: on, off, on-off, emergency stop.
XAP M molded, drilled and undrilled enclosures
- Zinc alloy, blue enclosure and lid- Drilling: 1 to 8 holesXAM W elbowed and drilled enclosures - Aluminium alloy, gray enclosure clearly and gray lid anthracite or yellow,- Drilling : 1 to 7 holes.
XAP E drilled, flush-mounting enclosures
- Faceplate in unpainted brushed aluminium- Drilling: 1 to 5 holes
- Compliance with IEC, UL, CSA standards- IP 65 dust and damp proofing- Same characteristics as components in the Harmony range - Range Benefits: At the heart of the action This range of industrial IP 67 enclosures combines simple installation, configuration flexibility, and robust construction. When combined with the metal buttons and LEDs of the Harmony range, it is perfectly suited for many typical operator dialog functions. - Range Application Presentation:
- Industry: machine manufacturers (automotive, textiles, timber)- Service sector and infrastructure: energy distribution, public works, building, airports

No detailed specifications are available for this product.
