Since 1952, MARECHAL ELECTRIC group has been one of the few major manufacturers in producing low voltage LT electrical connections within the industrial environment, either with or without the presence of an explosive atmosphere.
MARECHAL ELECTRIC is a French family business that specializes in low voltage electrical connectors from 5A to 1250A as well as electrical solutions for potentially explosive environments through the TECHNOR brand.
MARECHAL ELECTRIC offers a range of products that are intended for all sectors of industrial activity where safety and endurance are required, whilst ensuring their products are safe, durable, high performance, ease of use, and energy efficient.
EVO – The First Separable Switch-Disconnector
Furthermore, the EVO has a range of key features that provide a great benefit to your applications or projects such as: EVO is the safest switch disconnector with visible and distinctly obvious breaking.
EVO40 is a manually operated separable switch-disconnector, with configurations from 2 to 6 poles + Earth. EVO40 allows for frequent making and breaking on load, while ensuring safe isolation of any low voltage electrical circuit: resistive (AC-21A), mixed resistive/ inductive (AC-22A) or inductive (AC-23A).
EVO40 also allows for on load making and breaking of all electric motors (AC-3), as per IEC/EN 60943-3 standard requirements.
Thanks to the compact design, EVO40 can be configured to be panel-mounted or flush-mounted on a wall box with varying angles. Equipped with self-cleaning silver alloy contact tips and a unique and patented mechanism, Marechal ® EVO new technological concept combines the functionalities of a switch and an isolator. The design facilitates successive double breaking pole by pole, which ensures optimal safety during any maintenance operation.
Once the supply and load parts have been separated, a safety shutter prevents any risk of electric shock (IP4X/IPXXD). The robust mechanism allows distinctly and visibly separated disconnection and separation even in the event of overload currents.
The quality of EVO40 materials offers flexibility in the most demanding of applications in terms of hygiene, robustness, and reliability. In conjunction to this Marechal ® EVO meets variety of high ingress protection rating such as, IP66, IP67, IP69, and IK09.
EVO40 has a meets several certifications which include: LCIE BUREAU VERITAS to IEC/EN 60947-1 and 60947-3 standards.
